Shell Naturelle Transformer Fluid S4 I

Description

Product Description

Shell Diala S4 ZX-I is the new generation electrical insulating oil designed to meet the challenges posed by the latest power transformers. With an extended oil life and zero sulfur content, this premium oil ensures optimal performance and safety for your electrical equipment. Manufactured from zero sulfur base oils using Shell’s GTL (gas-to-liquid) technology, Shell Diala S4 ZX-I offers superior oxidation stability, excellent response to antioxidants, and global availability. Let’s explore the features, benefits, specifications, and more details about this remarkable insulating oil.

Performance of Shell Diala S4 ZX-I

• Extended Oil Life: Shell Diala S4 ZX-I is a fully inhibited oil that provides outstanding oxidation performance, resulting in a longer oil life.
• Transformer Protection: The zero sulfur content makes it intrinsically non-corrosive toward copper, eliminating the need for passivation or other additives. It meets both established and new industry copper corrosion tests.
• System Efficiency: The oil’s good low-temperature viscometric properties ensure proper heat transfer inside the transformer, even at very low starting temperatures.

Features of Shell Diala S4 ZX-I

1. Zero Sulfur Content: Manufactured from zero sulfur base oils using Shell’s GTL technology, ensuring a non-corrosive solution for copper components.
2. Fully Inhibited: Provides excellent oxidation stability and extends the oil life.
3. High Compositional Consistency: The base oils offer a high degree of consistency and response to antioxidants.
4. Free from PCBs, DBDS, and Passivators: Ensures environmental safety and compliance.
5. Meets Copper Corrosion Tests: Complies with DIN 51353, ASTM D1275, IEC 62535, and ASTM D1275B.

Benefits of Shell Diala S4 ZX-I

1. Reliability: Longer oil life reduces maintenance frequency and enhances transformer reliability.
2. Safety: Zero sulfur content minimizes the risk of copper corrosion and ensures safe operation.
3. Environmental Compliance: Free from harmful impurities and PCBs, promoting environmental responsibility.
4. Global Availability: Shell Diala S4 ZX-I is widely accessible, making it suitable for various applications worldwide.

Specifications

• Base Oil: Fischer-Tropsch derived hydrocarbon base oil
• Density @ 20°C: 805 kg/m³
• Kinematic Viscosity @ 40°C: 9.6 mm²/s
• Flash Point: 135°C
• Pour Point: -42°C
• Neutralization Value: 0.01 mg KOH/g
• Total Sulfur Content: Below 1 ppm detection limit of ASTM D5185

Certifications of Shell Diala S4 ZX-I

• IEC 60296 (Edition 5 year 2020): Type A, fully inhibited high-grade oil
• IEC 60296 Ed4 (2012): Table 2 Transformer Oil (I) (Inhibited oil) Section 7.1 (“Higher oxidation stability & low sulfur content”)

Health and Safety

• Shell Diala S4 ZX-I is unlikely to present any significant health or safety hazard when properly used.
• Avoid skin contact and use impervious gloves with used oil.
• Used oil may contain harmful impurities.
• Not classified as flammable but will burn.

Color of Shell Diala S4 ZX-I

The color of Shell Diala S4 ZX-I is clear, free from sediment, and suspended matter.

Applications

• Power transformers
• High voltage instrument transformers
• Bushings
• Refrigeration of servers by immersion

Industries Where Shell Diala S4 ZX-I Is Popular

• Power utilities
• Electrical equipment manufacturers
• Renewable energy installations
• Industrial plants
• Data centers

Price of Shell Diala S4 ZX-I

For pricing details and to purchase Shell Diala S4 ZX-I, please contact us. Our team will provide you with the best price for this high-quality insulating oil.

Flash Point of Shell Diala S4 ZX-I

The flash point of Shell Diala S4 ZX-I is 135°C.

Drop Point of Shell Diala S4 ZX-I

The drop point is not applicable for electrical insulating oils like Shell Diala S4 ZX-I.

Viscosity of Shell Diala S4 ZX-I

• Kinematic Viscosity @ 40°C: 9.6 mm²/s

Frequently Asked Questions (FAQs) about Shell Diala S4 ZX-I

1. Q: Is Shell Diala S4 ZX-I suitable for both new and existing transformers?
   • A: Yes, Shell Diala S4 ZX-I is suitable for both new and existing transformers. Its excellent oxidation stability ensures optimal performance over the long term.
2. Q: Can I mix Shell Diala S4 ZX-I with other insulating oils?
   • A: It is recommended to avoid mixing different insulating oils. Consult with a technical expert before making any changes.
3. Q: What is the shelf life of Shell Diala S4 ZX-I?
   • A: When stored properly, Shell Diala S4 ZX-I has a shelf life of several years. Keep it in a cool, dry place away from direct sunlight.
